Indoor design solutions

Indoor Design Solutions

Supports solutions for complex in-building projects such as Passive DAS, Wi-Fi and Small Cell networks

Rapid and Cost-Effective

Rapid and Cost-Effective

Delivering up 30% CAPEX/OPEX savings and increasing design productivity by 50%

Fast indoor 3D ray-tracing

Reliable Public Safety Networks

Ideal for designing indoor public safety networks

Multi-technology support

Multi-Technology Support

Supports multiple technologies such as 5G NR, 4G (LTE), 3G, IoT, Wi-Fi, TETRA, PMR, DMR and P25

Features

Simple In-Building Network Planning Tool

Ranplan In-Building Lite incorporates all the latest 5G, Public Safety and Wi-Fi technologies to design and optimise indoor wireless coverage.

in-building-lite-screenshot
NETWORK DESIGN

Accelerate In-Building Network Delivery

Simplify and speed up the process of designing in-building cellular, public safety and Wi-Fi wireless networks with the Intelligent Topology Optimisation (ITO) module which automatically and efficiently optimises the physical topology of an in-building network.

Laptop-PRO-IFC
  • Create 3D building models in just minutes by importing IFC (Industry Foundation Classes) files from various BIM (Building Information Modelling) authoring software, such as Revit, Edificius, ArchiCAD, EdiLus®, SketchUp®, VectorWorks®, Rhino®, Tekla® and more.
  • Seamlessly import 3D IFC building models from the Metaroom® LiDAR scanning app.
  • Automatically reconstruct 3D building models from imported 2D Auto CAD floorplans.
  • The Intelligent Floorplan Recognition (IFR) tool assists in modelling your environments from images or drawings when official floorplans are unavailable.
in-building-lite-floorplan-prediction
  • Intelligent Design Modules for passive DAS, small cells, non-fibre based public safety networks.
  • Duplicated system design between floors of the same building.
  • Automatic cable length measurement of coaxial, radiating and jumper cables.
  • Access our large multi-vendor component database to populate your network with verified devices.
Building-2-dark-1
NETWORK PERFORMANCE

Validate Indoor Coverage Prior to Deployment

Ensure your in-building network designs will deliver reliable signal strength in times of emergency by using Ranplan’s 3D ray-tracing propagation engine to validate indoor coverage performance before physical deployment. This will save time and cost in subsequent upgrades.

  • True 3D ray-tracing propagation engine for predicting wireless coverage inside indoor environments before physical deployment.
  • Visualise the indoor wireless coverage on 3D heatmaps to quickly identify not-spots.
  • Define candidate and target region Key Performance Indicators (KPIs) such as signal, throughput and leakage.
  • Supports designs for passive DAS, small cells and Wi-Fi networks.
Access real-time actionable insights
ADVANCED REPORTING

Track Project Progress and Monitor Costs

Use the powerful and automatic reporting feature in Ranplan In-Building Lite to gain real-time project information and reports at the simple click of a button. This will help ensure projects remain on track and meet customers’ requirements.

  • Automated reports providing real-time updates.

  • Choose from multiple reports including equipment list, equipment budget report, cable routing, cross-reference and Bill of Materials.

  • Evaluate antenna performance with Antenna EIRP and Antenna Link Budget reports.

  • Maintain compliance with EMF regulations using the dedicated report.

  • Easily print Network System Design and Floor Layout Design documents

Download Datasheet Book a Demo
FAQs

Frequently Asked Questions

Can’t find the answer you are looking for below? Visit our full library of FAQs for more information or get in touch if you still need help.

Can I create custom report templates within Ranplan Products and if so how?

Yes, users can create their own custom layouts for reports within Ranplan Products. For detailed information on how to do this please refer to the user documentation for the relevant software package.

Where/how can I access the download package for the latest versions of Ranplan?

The latest versions of Ranplan Professional, DAS and Tablet can be downloaded from the ‘Downloads’ section of your account on the GLS end user portal. Please note that you will only have access to the install packages for which you have license keys.

How accurate is the default propagation model used in Ranplan?

Under general circumstances the 3D ray-tracing model is accurate to within 6dB RMS error of the measured scenario and this has been independently verified.

How does ‘CAD Import’ in Ranplan differ from the current functionality offered by other suppliers?

The Smart Extract tool within Ranplan takes a much more visual approach to identifying walls, doors, windows, columns and inclined planes with no need to interact with the many layers in the CAD file.

What type of algorithm is used in the optimization modules and what does that mean for me as a user?

The optimization modules (ICO, IAO and IFO) all use heuristic algorithms to determine the results they provide. This means that the optimization modules will attempt to provide the best outcome based upon the restrictions or parameters provided by you, the user.

View All FAQs

Find out how to design indoor networks faster, easier, and more affordably with Ranplan In-Building Lite
